Description
The VARIODECK slab table is ideal for projects where large slab areas have to be formed in a short time. The tables can be used for ceilings up to 50 cm.
They always require only four floor props and can be moved in one crane lift. If necessary, stronger slabs with correspondingly more supports can be formed.
Advantages
- The maximum formwork area of a table is 15.9 m².
- When using the tables at the edge of the ceiling, a working platform is already integrated into the system and no additional fall protection is required.
- For fast and easy stripping or horizontal movement, a table lift or transfer carriage is used.
- Free choice of props and increase of prop loads possible by clamping the floor prop in the table swivel head.
- Fitting ranges up to a maximum of 50 cm can be realized without additional support.
- System-integrated connections are used to dissipate the horizontal forces.
- Due to the low overall height of only 36 cm, little transport and storage volume is required.
Here you can find a link for downloading the brochure:
